Q CELLS Q.HOME+ 6kW/18.9kWh Hybrid Battery Inverter, HQCAESS1106

Description

Q CELLS Q.HOME+ 6kW/18.9kWh Hybrid Battery Inverter, HQCAESS1106

The Q.HOME+ ESS HYB-G1/AC-G1 energy storage solution offers scalable storage capacity from 4.5 kWh up to 18.95 kWh and comes in a modular design for easy and fast installation. The system is offered in both DC-coupled and AC-coupled configurations and can connect up to three batteries in series using only one inverter and battery management system (BMS). The system includes an integrated backup power function for 100% of the rated inverter output to support critical loads in the event of power failure and offers remote monitoring using the Q.HOME+ web portal or Q.HOME+ ESS mobile app.

Technical Specifications

Continuous AC Power Output

6 kW

Max Operating Voltage

120, 240 V

AC Voltages

120/240 VAC

AC Frequencies

60 Hz

Maximum DC Input Voltage

600 VDC

Maximum DC Input Current

25 A

Peak Efficiency

96.7 %

CEC Efficiency

95.67 %

Enclosure Ratings

NEMA 4X

General Information

Approvals

UL 1741
